| Business Type | Manufacturer, Exporter, Supplier, Trader |
| Driven Type | Electric |
| Automatic Grade | Automatic |
| Application | Film Making |
| Click to view more | |
Product Details
Type
Film Machinery
Country of Origin
India
Model
SS/SF-55/75/55-1000
Screw Dia
55-75-55 mm
Finished Film Width
1000 MM (500 x 2)
A Cast Surface Protection Film Making Machine is used to manufacture thin, flexible films that are designed to protect surfaces from scratches, dirt, and other damage during transportation, storage, or construction. These films are commonly used in various industries, including:
- Automotive
- Electronics
- Construction
- Furniture
- Appliances
PE (Polyethylene) Film: This is the most common type of surface protection film due to its excellent clarity, flexibility, and cost-effectiveness.
Advantages of Cast Surface Protection Films:
- Protection: Effectively shield surfaces from scratches, dust, and other damage.
- Easy Application and Removal: Can be easily applied and removed without leaving any residue.
- Cost-Effective:/ Protect expensive surfaces at a fraction of the cost of replacement.
- Customizable: Can be customized to meet specific requirements in terms of thickness, clarity, and adhesive strength.
Specification
| Model | SS/SF-55/75-1000 | SS/SF-45/65/45-1000 | SS/SF-55/90/55-1500 | SS/CF-75/100/75-2000 | SS/CF-75/120/75-2500 | |
| Material | LLD/LD/PIB | LLD/LD/PIB | LLD/LD/PIB | LLD/LD/PIB | LLD/LD/PIB | |
| Screw Size (MM) | 55/75 | 45/65/45 | 55/90/55 | 75/100/75 | 75/120/75 | |
| Film Width (MM) | 1000 (Finished) | 1000 (Finished) | 1500 (Finished) | 2000 (Finished) | 2000 (Finished) | |
| T-Die Width (MM) | 1250 | 1250 | 2300 | 2800 | ||
| Max. Extrusion Output (Kg/Hr) | 120 | 120 | 150-220 | 150-280 | 200-320 | |
| Winder | Surface Roll Winder with Auto Cutting & Reel Changeover System by PLC | |||||
| Machine Dimension (Mtrs) (L x W xH) | 12 x 4 x 5 | 15 x 5 x 5.5 | 17 x 6 x 6 | 19 x 7 x 6.5 | 22 x 8 x 6.5 | |
